Model
|
IPCFCZ37EA
|
|
Camera
|
|
|
Image Sensor
|
1/2.8" SO-NY IMX335 CMOS
|
|
Effective Pixels
|
3072 (H) × 2048 (V)
|
|
Electronic Shutter
|
AUTO, 1/25s ~ 1/100000s
|
|
Min. Illumination
|
0.01Lux@F1.2(AGC ON), 0Lux IR on
|
|
Day/Night
|
Auto/Color/(B/W)/Timing
|
|
WDR
|
Digital WDR
|
|
White Balance
|
Auto/Indoor/Outdoor
|
|
BLC
|
Support
|
|
DNR
|
2D/3D DNR
|
|
Other
|
Human body and Vehicle detection ,Motion Detection, Privacy Mask, Mirror, flip
|
|
Encode
|
|
|
Embedded Solution
|
SSC377D
|
|
Video Standard
|
H.264/H.265
|
|
Video Resolution
|
Main Stream:25fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc.
Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc. |
|
Video Bitrates
|
512Kbps - 10Mbps, VBR/CBR
|
|
Audio Standard
|
G.711-u/G.711-a/AAC
|
|
OSD Overlay
|
Title and Time overlay
|
|
LedS
|
|
|
Leds
|
2PCS warm lights
|
|
distance
|
25-30M
|
|
Lens
|
|
|
Focal length
|
HD 2.8mm F1.0 lens
|
|
Functions
|
|
|
Built in Microphone
|
|
|
Network Services
|
|
|
Protocol
|
HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.
|
|
P2P
|
Yes
|
|
Web
|
IE , Firefox,Edge, Google Chrome etc.
|
|
Media
|
CMS, Android, IOS
|
|
General
|
|
|
Network Port
|
1-RJ45, 100Mbps
|
|
Power Supply
|
POE ,12 VDC ± 10%
|
|
Power Consumption
|
< 8 W
|
|
Operating Temp.
|
-30℃-(+60)℃, 10%-90%RH
|
